TECHNICAL SPECIFICATION

GLAZED PROCELAIN TILES
-POLISH (PGVT)

CHARACTERISTICS STANDARD AS PER ISO-13006/EN14411 GROUP BLA SPINORA VALUE TEST METHOD
REGULATORY PROPERTIES . . .
Deviation in length & width ± 0.5% ± 0.1% ISO-10545-2
Deviation in thickness ± 0.5% ± 4.0% ISO-10545-2
Straightness in sides ± 0.5% ± 0.1% ISO-10545-2
Rectangularity ± 0.5% ± 0.1% ISO-10545-2
Surface flatness ± 0.5% ± 0.2% ISO-10545-2
Surface quality Min. 95% defect free > 95% ISO-10545-2
Glossiness > 90 GU > 92 GU Gloss meter 60°
STRUCTURAL PROPERTIES . .
Water absorption < 0.50% < 0.05% ISO-10545-3
Apparent density > 2.0 g/cc > 2.20 g/cc DIN 51082
MASSIVE MECHANICAL PROPERTIES . .
Modulus of rupture > 35 N/mm2 > 40 N/mm2 ISO-10545-4
Breaking strength > 1300 N > 1800 N ISO-10545-4
Impact resistance (COR) >0.55 >0.55 ISO-10545-5
SURFACE MECHANICAL PROPERTIES . .
Surface abrasion resistance Declared class Class PEI 4 (2100 revolutions) EN 154
Surface scratch hardness (Mohs scale) 5 5 EN 101
THERMO HYGROMRTRIC PROPERTIES . .
Frost resistance Test passed in accordance with test method Pass ISO-10545-12
Thermal shock resistance Min. 10 cycle Pass ISO-10545-9
Moisture expansion 0.06mm/m 0.01mm/m ISO-10545-10
Thermal expansion (COE) Max. 9.0 x 10 Max. 6.5 x 10 ISO-10545-8
Crazing resistance No damage No damage ISO-10545-11
CHEMICAL PROPERTIES . .
Chemical resistance No damage No damage ISO-10545-13
Stain resistance Min. Class 3 Class 5 ISO-10545-14
SAFETY PROPERTIES . .
Slip resistance (COF) Declared value > 0.40 dry, <0.40 wet ISO-10545-17
Reaction to fire Class A1 or A1 fl Class A1 - A1 fl N.A.

GLAZED PROCELAIN TILES
-HIGH GLOSSY (PGVT)

CHARACTERISTICS STANDARD AS PER ISO-13006/EN14411 GROUP BLA SPINORA VALUE TEST METHOD
REGULATORY PROPERTIES . . .
Deviation in length & width ± 0.5% ± 0.1% ISO-10545-2
Deviation in thickness ± 5.0% ± 4.0% ISO-10545-2
Straightness in sides ± 0.5% ± 0.1% ISO-10545-2
Rectangularity ± 0.5% ± 0.1% ISO-10545-2
Surface flatness ± 0.5% ± 0.2% ISO-10545-2
Surface quality Min. 95% defect free > 95% ISO-10545-2
Colour difference Unaltered Unaltered ISO-10545-16
Glossiness > 90 GU > 92 GU Gloss meter 60°
STRUCTURAL PROPERTIES . .
Water absorption < 0.50% < 0.05% ISO-10545-3
Apparent density > 2.0 g/cc > 2.20 g/cc DIN 51082
MASSIVE MECHANICAL PROPERTIES . .
Modulus of rupture > 35 N/mm2 > 40 N/mm2 ISO-10545-4
Breaking strength > 1300 N > 1800 N ISO-10545-4
Impact resistance (COR) >0.55 >0.55 ISO-10545-5
SURFACE MECHANICAL PROPERTIES . .
Surface abrasion resistance Declared class Class PEI 3 EN 154
Surface scratch hardness (Mohs scale) 5 5 EN 101
THERMO HYGROMRTRIC PROPERTIES . .
Frost resistance Test passed in accordance with test method Pass ISO-10545-12
Thermal shock resistance Min. 10 cycle Pass ISO-10545-9
Moisture expansion 0.06mm/m 0.01mm/m ISO-10545-10
Thermal expansion (COE) Max. 9.0 x 10 Max. 6.5 x 10 ISO-10545-8
Crazing resistance No damage No damage ISO-10545-11
CHEMICAL PROPERTIES . .
Chemical resistance No damage No damage ISO-10545-13
Stain resistance Min. Class 3 Class 5 ISO-10545-14
SAFETY PROPERTIES . .
Slip resistance (COF) Declared value > 0.40 dry, <0.40 wet ISO-10545-17
Reaction to fire Class A1 or A1 fl Class A1 - A1 fl N.A.

GLAZED PROCELAIN TILES
-MATT, MATT WITH STRUCTURE

CHARACTERISTICS STANDARD AS PER ISO-13006/EN14411 GROUP BLA SPINORA VALUE TEST METHOD
REGULATORY PROPERTIES . . .
Deviation in length & width ± 0.5% ± 0.1% ISO-10545-2
Deviation in thickness ± 5.0% ± 4.0% ISO-10545-2
Straightness in sides ± 0.5% ± 0.1% ISO-10545-2
Rectangularity ± 0.5% ± 0.1% ISO-10545-2
Surface flatness ± 0.5% ± 0.2% ISO-10545-2
Surface quality Min. 95% defect free > 95% ISO-10545-2
STRUCTURAL PROPERTIES . .
Water absorption < 0.50% < 0.05% ISO-10545-3
Apparent density > 2.0 g/cc > 2.20 g/cc DIN 51082
MASSIVE MECHANICAL PROPERTIES . .
Modulus of rupture > 35 N/mm2 > 40 N/mm2 ISO-10545-4
Breaking strength > 1300 N > 1800 N ISO-10545-4
Impact resistance (COR) >0.55 >0.55 ISO-10545-5
SURFACE MECHANICAL PROPERTIES . .
Surface abrasion resistance Declared class Class PEI 4 (2100 revolutions) EN 154
Surface scratch hardness (Mohs scale) 5 5 EN 101
THERMO HYGROMRTRIC PROPERTIES . .
Frost resistance Test passed in accordance with test method Pass ISO-10545-12
Thermal shock resistance Min. 10 cycle Pass ISO-10545-9
Moisture expansion 0.06mm/m 0.01mm/m ISO-10545-10
Thermal expansion (COE) Max. 9.0 x 10 Max. 6.5 x 10 ISO-10545-8
Crazing resistance No damage No damage ISO-10545-11
CHEMICAL PROPERTIES . .
Chemical resistance No damage No damage ISO-10545-13
Stain resistance Min. Class 3 Class 5 ISO-10545-14
SAFETY PROPERTIES . .
Slip resistance (COF) Declared value > 0.40 dry, <0.40 wet ISO-10545-17
Reaction to fire Class A1 or A1 fl Class A1 - A1 fl N.A.

GLAZED PROCELAIN TILES
-SUGAR, LAPATO (PGVT)

CHARACTERISTICS STANDARD AS PER ISO-13006/EN14411 GROUP BLA SPINORA VALUE TEST METHOD
REGULATORY PROPERTIES . . .
Deviation in length & width ± 0.5% ± 0.1% ISO-10545-2
Deviation in thickness ± 5.0% ± 4.0% ISO-10545-2
Straightness in sides ± 0.5% ± 0.1% ISO-10545-2
Rectangularity ± 0.5% ± 0.1% ISO-10545-2
Surface flatness ± 0.5% ± 0.2% ISO-10545-2
Surface quality Min. 95% defect free > 95% ISO-10545-2
STRUCTURAL PROPERTIES . .
Water absorption < 0.50% < 0.05% ISO-10545-3
Apparent density > 2.0 g/cc > 2.20 g/cc DIN 51082
MASSIVE MECHANICAL PROPERTIES . .
Modulus of rupture > 35 N/mm2 > 40 N/mm2 ISO-10545-4
Breaking strength > 1300 N > 1800 N ISO-10545-4
Impact resistance (COR) >0.55 >0.55 ISO-10545-5
SURFACE MECHANICAL PROPERTIES . .
Surface abrasion resistance Declared class Class PEI 4 (2100 revolutions) EN 154
Surface scratch hardness (Mohs scale) 5 5 EN 101
THERMO HYGROMRTRIC PROPERTIES . .
Frost resistance Test passed in accordance with test method Pass ISO-10545-12
Thermal shock resistance Min. 10 cycle Pass ISO-10545-9
Moisture expansion 0.06mm/m 0.01mm/m ISO-10545-10
Thermal expansion (COE) Max. 9.0 x 10 Max. 6.5 x 10 ISO-10545-8
Crazing resistance No damage No damage ISO-10545-11
CHEMICAL PROPERTIES . .
Chemical resistance No damage No damage ISO-10545-13
Stain resistance Min. Class 3 Class 5 ISO-10545-14
SAFETY PROPERTIES . .
Slip resistance (COF) Declared value > 0.40 dry, <0.40 wet ISO-10545-17
Reaction to fire Class A1 or A1 fl Class A1 - A1 fl N.A.

GLAZED PROCELAIN TILES
-WOODEN TILES (GVT)

CHARACTERISTICS STANDARD AS PER ISO-13006/EN14411 GROUP BLA SPINORA VALUE TEST METHOD
REGULATORY PROPERTIES . . .
Deviation in length & width ± 0.5% ± 0.1% ISO-10545-2
Deviation in thickness ± 5.0% ± 4.0% ISO-10545-2
Straightness in sides ± 0.5% ± 0.1% ISO-10545-2
Rectangularity ± 0.5% ± 0.1% ISO-10545-2
Surface flatness ± 0.5% ± 0.2% ISO-10545-2
Surface quality Min. 95% defect free > 95% ISO-10545-2
Glossiness > 90 GU > 92 GU Gloss meter 60°
STRUCTURAL PROPERTIES . .
Water absorption < 0.50% < 0.05% ISO-10545-3
Apparent density > 2.0 g/cc > 2.20 g/cc DIN 51082
MASSIVE MECHANICAL PROPERTIES . .
Modulus of rupture > 35 N/mm2 > 40 N/mm2 ISO-10545-4
Breaking strength > 1300 N > 1800 N ISO-10545-4
Impact resistance (COR) >0.55 >0.55 ISO-10545-5
SURFACE MECHANICAL PROPERTIES . .
Surface abrasion resistance Declared class Class PEI 4 (2100 revolutions) EN 154
Surface scratch hardness (Mohs scale) 5 5 EN 101
THERMO HYGROMRTRIC PROPERTIES . .
Frost resistance Test passed in accordance with test method Pass ISO-10545-12
Thermal shock resistance Min. 10 cycle Pass ISO-10545-9
Moisture expansion 0.06mm/m 0.01mm/m ISO-10545-10
Thermal expansion (COE) Max. 9.0 x 10 Max. 6.5 x 10 ISO-10545-8
Crazing resistance No damage No damage ISO-10545-11
CHEMICAL PROPERTIES . .
Chemical resistance No damage No damage ISO-10545-13
Stain resistance Min. Class 3 Class 5 ISO-10545-14
SAFETY PROPERTIES . .
Slip resistance (COF) Declared value > 0.40 dry, <0.40 wet ISO-10545-17
Reaction to fire Class A1 or A1 fl Class A1 - A1 fl N.A.

GLAZED PROCELAIN TILES
-WALL TILES (GVT)

CHARACTERISTICS STANDARD AS PER ISO-13006/EN14411 GROUP BLA SPINORA VALUE TEST METHOD
REGULATORY PROPERTIES . . .
Deviation in length & width ± 0.5% ± 0.1% ISO-10545-2
Deviation in thickness ± 5.0% ± 4.0% ISO-10545-2
Straightness in sides ± 0.5% ± 0.1% ISO-10545-2
Rectangularity ± 0.5% ± 0.1% ISO-10545-2
Surface flatness ± 0.5% ± 0.2% ISO-10545-2
Surface quality Min. 95% defect free > 96% ISO-10545-2
PHYSICAL PROPERTIES . .
Water absorption > 10% > 12-18% ISO-10545-3
Modulus of rupture > 12 N/mm2 > 18 N/mm2 ISO-10545-4
Breaking strength > 600 N > 800 N ISO-10545-4
Frost resistance Test passed in accordance with test method Pass ISO-10545-12
Thermal shock resistance Min. 10 cycle Pass ISO-10545-9
Moisture expansion 0.06mm/m 0.01mm/m ISO-10545-10
Thermal expansion (COE) Max. 9.0 x 10−6 Max. 5 x 10−6 ISO-10545-8
Crazing resistance No damage No damage ISO-10545-11
CHEMICAL PROPERTIES . .
Chemical resistance No damage No damage ISO-10545-13
Stain resistance Min. Class 3 Class 5 ISO-10545-14
